Linear regression is a statistical model used to predict continuous values of a response variable as a function of one or more predictor variables. For example, we could build a linear regression model to predict a person’s height as a function of age, weight and gender. In this case, the response variable (height) is continuous and can take any value within a specific range.
On the other hand, logistic regression is a statistical model used to predict discrete values of a response variable as a function of one or more predictor variables. In this case, the response variable is binary (0 or 1) and represents the presence or absence of an event or condition. For example, we could build a logistic regression model to predict whether or not a person has diabetes as a function of age, weight and level of physical activity.
Although these two types of models look different, they actually share some common features. Both models use a mathematical function that relates the predictor variables to the response variable. In linear regression, this function is a straight line, while in logistic regression, it is a sigmoid function.
In addition, both models use coefficients to measure the strength of the relationship between the predictor variables and the response variable.
In linear regression, these coefficients (slopes) represent the change in the response variable when one of the predictor variables changes by one unit.
In logistic regression, the coefficients represent the change in the probability that the response variable equals 1 when one of the predictor variables changes by one unit.
In order to better understand this relationship and to interpret the logistic regression coefficients appropriately, the following basic concepts must be kept in mind:
- Probability
- Odds
- Odds ratio
#Probability
Definition: Measure of the degree of certainty that an event may occur. Calculation: Number of times the event occurs/total number of trials. Scale: Number between 0 and 1. Where 0 equals an impossible event and 1 equals a certain event.
I have played a card game 5 times, in which I have won 3 times and lost 2 times. According to this sample, my probability of winning is 0.6.
p(win) = 3/5 = 0.6
#Odds
Definition: A measure of the relative probability of an event occurring versus not occurring. Calculation: ratio between the probability of the event happening/probability of it not happening. Scale: ranges from 0 to infinity.
I have played a card game 5 times, in which I have won 3 times and lost 2 times. According to this sample data, winning is 1.5 times more likely than losing.
odds(win) = (3⁄5)/(2⁄5) = 1.5
#Odds Ratio
Definition: allows to compare the odds of an event in two groups. Calculation: it is the division between the odds of event X in one group and the odds of event X in another group. Scale: ranges from 0 to infinity.
I have played a card game 5 times, in which I have won 3 times and lost 2 times. After that, I have tried a different game and played it 5 times, in which I have won 1 time and lost 4 times. According to this sample data, winning in the first game is 6 times more probable than winning in the second game.
Odds (win1) = (3⁄5)/(2⁄5)= 1.5
Odds (win2) = (1⁄5)/(4⁄5)= 0.25
Odds ratio(win) = Odds (win1)/Odds (win2) = 6
